Most older homes were built before building codes were part of the construction industry and these houses were built by various immigrants who had their own ways of building houses.  It is very rare that we find a house that was built according to any of the seismic retrofit building guidelines.  The drawings here illustrate some of the unusual framing we find under these old houses and if you find a house that is not built by the book look at these drawings until you find the one that matches your house and retrofit it as shown.  If you can’t find it please write to me and I probably have a drawing somewhere that will match your need.

Balloon Framing

Longitudinal balloonframing with H-10R’s

Longitudinal balloonframing with plywood blocks

Transverse balloonframing with 2by to ledger

Transverse balloonframing with plywood to ledger



Education – Basic Engineering

Diagram – 16,000 Pounds of force each side-2arrowheads

Diagram – 14 stt’s each side

Diagram – 14 ft of plywood each side

Diagram – 14 bolts each side



Education – What Happens

Unreinforced – reinforced cripple wall defined

General Diagram – Typical failue points

General Diagram – Transfer Tie Failure

General Diagram – Transfer Tie Failure Horizontal

General Diagram – Cripplewall Failure

General Diagram – Cripplewall Failure TWO

General Diagram – cripple wall by stairs

General Diagram – Bolt Failure

General Diagram – Bolt Failure TWO

Cripple wall – 3 EQ forces consequences



Education –  Overturning Forces

General Diagram – Overtunring + holddowns no force

General Diagram – Overtunring, holddowns pull on fdn

General Diagram – Overturning, holddown with cement blocks

General Diagram – Overturning, no holddowns, closeup.

General Diagram – Overturning, no holddowns,sill tears

General Diagram – Overturning, no uplift

General Diagram – Overturning,holddowns fdn breaks

General Principles – Concrete under hold down close detail

Stick house – Overturning forces



Education – Shear Wall Construction

General Diagram – Cripplewall Failure General Principles – Nailing of plywood

General Principles – Shear panel – stepped foundation

General Principles – Shearwall framing

General Principles Load Path

General Principles Rreinforced cripple wall only.

General Principles Shear Wall – structural components



Education – Don’t Ignore Top Plates

EQ forces travel thru break in topplate

General Principles – Topplate splice

Topplate splice nailed close up



Education – Misc.

General Diagram – cripple wall by stairs

General Diagram – Ground stationary and house moves

Shear Wall Deformation – rectangle



Lag Floor Connectors – Save The Ceiling Drywall

LAG SCREW

Lag Bolts Detail

Lag bolts – front view



Misc.

Addition -Tension tie

Cross-grain bending

Double mudsill with LTP-4s

Foundation Follows Porch

Wall obstruction detail



Missing Top Plates

Missing topplate – 2by to next joist

Missing topplate – ply DIA to next joist

Missing topplate-Sistered 2by



New Footings

New footing and shear wall to one joist,

New footing and shear wall to two joists one story

New footing and shear wall to two joists two story

New footing and shear wall with plywood blocking



Shear Wall Repairs

Shearwall repair – DIA stapled to existing shear wall with 2×10

Shearwall Repair – staple 2by to subfloor

Shearwall repair- ply DIA to next joist

Shearwall repair-no blocking-flushcut repair



Short Shear Wall

Short Shearwall – UFP and 2 x 10 shear wall

Short Shearwall – UFP with 2×4 sistered to topplate+2×10

Short Shearwall – UFP with 2×4 sistered to topplate+L-90

Short Shearwall – UFP with plywood shear wall



New Sill to Side of Foundation

Sidebolt, capped transverse 2 joists

Sidebolt-longitudinal capped wall

Sidebolt – 4×4.to side, obstruction bypass



Sidebolt – 2×8 and 2by DIA

Sidebolt -2×8 direct to joist

Sidebolt -2×8 LTP4 direct to joist

Sidebolt -2×8, plywood to next joist

Sidebolt -2×8. ply+ blocking to joist BAUM



Side Bolt –  No Cripple Wall, No Blocking

Sidebolt 2 x 8 and .75 ply 7 inch bolt

Sidebolt no blocking, 2 x 8 and 1 1-8th ply



Sill Connections

Sill connection – Four panel flush cut



Nailed Blocking

Detail – blocked UFP Sill Connection –

Four Panel Nailed Blocks Sill Connecton –

Nailed Blocks, two panel



Reverse Blocking

Reverse block – bolts in wide foundation

Sill Connection – Reverse Block narrow sill

Sill Connection – Four panel reverse blocking

Sill Connection – Reverse blocking + UFP

Sill Connection – Reverse Block Breakdown

Sill Connection – Reverse blocking + bolt

Sill Connection- Three panel reverse blocking



Stapled Blocking

Sill Connection – Four Panel Stapled Blocks

Sill Connection – Stapled Blocks

Sill Connection Plywood stapled to blocks.

Sill Connecton – plywood stapled to blocks.

ZX Sill Connection – Stapled Blocks



Staple to Floor

Sidebolt -staple plywood to floor Short shearwall

Sidebolt -staple plywood to floor, 2 x 12 and ply

Sidebolt -staple plywood to floor, 2 x 8 and ply



Splices

General Principles – Horizontal seam – sheetmetal splice

General Principles – Horizontal stapled splice

General Principles – Topplate splice

Topplate splice nailed close up



URFP Details

Detail – blocked UFP

UFP and L90 Perp

URFP and L90 Parallel
